Tubes & Pipes

Caption aligned here

Tubes & Pipes | Pipe Tube Fabrication

Tube & Pipes as our major biz for various applications

KBIS has chosen Manufacturer of tubes & pipes & Raw material producer to fabricate tubes pipes.

For our own project, we supply materials, fabricate tubes by O.E.M contractor with competitive price. Above all, we work with people with a goodwill to establish a fine product basis on outstanding quality control system. We believe that establishment & operation of a good system only comes from understanding the philosophical value of making better world by supplying safe & qualified products to industrial sectors.

KBIS carries a role of project coordinator.

KBIS shall examine imbedded risks & opportunities in executing projects in supplying raw materials, semi finished products, fabrication services, and consultation service to customers. In performing the roles of KBIS company, work process of each project work might differ, but the foundation of work execution shall reviewing Internal control system of a manufacturer complying with key values of ISO:9001 as starting point.

Carbon & Alloy Pipe for Oil & Gas Applications

API 5l PSL 1 & PSL 2
API 5CT J55, K55, N80-1, N80-Q,P110
ASTM A53 for Pipe, Steel, Black & Hot-Dipped, Zinc-Coated, Welded & Seamless
ASTM A134 & A139 for Pipe, Steel, Electric –Fusion (ARC)-Welded Steel Pipe NPS 16 & Over, NPS 4 & Over
ASTM A252 for Welded & Seamless Steel Pipe Piles.
ASTM A671 for Electric-Fusion-Welded Steel Pipe for Atmospheric & Lower Temp.
ASTM A672 for Electric-Fusion-Welded Steel Pipe for High-Pressure Service at moderate Temp.
ASTM A691 for Carbon & Alloy Steel Pipe, Electric-Fusion-Welded for High-Pressure Services at High Temp

Seamless Carbon & Alloy Tubes & Pipes

SA/A179 : Seamless cold drawn low carbon steel tubes for tubular heat exchanger & condenser tubing
SA/A192 : Specification for seamless carbon steel boiler tubes for high pressure service
SA/A210 : Seamless medium carbon steel boiler & super heater tubes
SA/A213 : Seamless ferritic & austenitic alloy steel boiler, super heater & austenitic steel
heat-exchanger tubes
SA/A334 : Seamless & Welded carbon and alloy-steel tubes at low temperatures
SA/A333 : Seamless & Welded steel pipe for use at low temperature
SA/A335 : Seamless Ferritic Alloy-steel Pipe for High-temperature service
Product Rage
O.D 12.7mm – 406.4 mm, W.T : 0.8mm – 40.49mm Length Max. 24,000mmL

Stainless ProductsSeamless & Welded Stainless Steel Pipes

ASTM A312 for Seamless, Welded, & Heavily Cold Worked Austenitic Stainless Steel Pipes
ASTM A358 for Electric-Fusion-Welded Austenitic Chromium Nickel Stainless Steel Pipe for High-Temp. service & General Applications
ASTM A409 for Welded Large Diameter Austenitic Steel Pipe for corrosive or High Temperature Service
ASTM A790 for Seamless & Welded Ferritic / Austenitic Stainless Steel Pipe
ASTM A928 for Seamless & Welded Ferritic / Austenitic Stainless Steel Pipe Electric Fusion Welded with Addition of Filler Material.
Product Rage
Welded Pipe Sizes : Max O.D 60” (1,524mm) Max.W.T.: 23mm, Length 6,000mmL
Seamless Pipe Sizes : O.D 1/4”(13.72mm) – 12”(323.85mm), W.T.: 97.5mm, Length 6,000mmL

Stainless steel & Duplex Steel Grades

Stainless steel & Duplex Steel Grades
TP304, TP316, TP317, TP321, TP310S, TP347, SD30432, S31245 (L,H,N,LN)
PIPE : ASTM A312, A376,A790 / JIS G3459
O.D.: 1/8” – 10” (10.5 -273.1mm)
W.T.: SCH5S – XXS (1- 23mm)
TUBE : ASTM A213, A268, A269, G3463
O.D.: 10 – 120 mm
W.T.: 1 – 30mm

S32304, S31803, S32750/60, S31500
HOT FINISHED
O.D.: 40 -273.1mm
W.T.: 4mm or more

COLD FINISHED
O.D.: 19.05 – 110 mm
W.T.: 1.65mm or More

Widely Used Materials & Equipment in Oil & Gas

Different types of steel have different uses in the oil and gas industry.
The various types of steel and their uses in the oil and gas industry are mentioned below:

Stainless Steel

This is a type of iron steel that provides complete protection against corrosion. It is used in the oil and gas industry for making flowlines, structural components, heat exchangers, umbilicals and processing equipment. There are other applications of stainless steel in the oil and gas industry. It is used in kitchen appliance and catering equipment, construction and building, and for transport purposes.

Duplex Stainless Steel

Duplex stainless steel is strong and has a high corrosion resistance and stress corrosion cracking properties. In oil and gas industry, it is used in storage tanks and pressure wells, petrochemicals, bridges, swimming pools, storage and transportation, etc.

Forged Steel

Forged steel is generally used where its steel strength heaviness is required. It is commonly used in valves and fittings, automotive parts, hand tools and hardware, mining equipment, construction equipment, shipbuilding, etc.

Engineering Steel

Engineering steel is known as a special type of bar quality steel. It is mainly used in large equipment, shafts and bearings, drill bits, automotive parts, hand tools, industrial machinery, etc.

Carbon Steel

Carbon steel is strong and has a high resistance to wearing. It is the most widely used type of steel in the oil and gas industry. It is used in making flowlines, structural components, pipelines, platforms, etc.

Steel in some form or the other has various uses in the oil and gas industry. Apart from the ones mentioned above, there are numerous other uses of steel in this field. The professional steel fabricators can let you know of the same. As steel has so many applications and uses in the oil and gas industry, it continues to be the most common and popular metal in this industry.
